Default Ford Ranger build log V.2

For anyone who was following my last build log, I sold my obsidian 15"s and Saz-1500v3 to a local buddy. Here they are loaded up and headed to their new home.



On to the new build. Here's a list of equipment.

2 Sundown X-15's D4
DD M3b
2 Juicebox blackcherry batteries.
1 Xs power D1200
Excessive amperage 300 amp Internally regulated Alt.
100' 2/0 welding cable
Soundstream 600.4
1 set of crescendo CZ 6.5 components.

Onto the pics.

Here are the 15's





These things are beast, surround is massive.

Onto the amp. DD M3b



Heres the alt.




Old vs. New

Here's the second Juicebox battery.


More to come.
