Default RAMROD's Bass Upgrade- American Bass,Mechman,Odyssey,XS Power,ToolMaker,CSCStang....


I have been collecting parts for some time on this build and I couldn't have done it without the help from these Companies and many of the forum members here..
Huge thanks goes out to Odyssey Batteries, XS Power, Mechman Alternators, American Bass, Toolmaker Metalworkz and of course CSCStang for a Custom box.
Parts List as of now...It may grow
CSCStang - Custom Box
Mechman Alternator - 240a
American Bass 4480.1D Amp 2200 @ 1Ohm
American Bass XR-12 1200w RMS
Odyssey PC1350-A for Main Battery
XS Power XP750-CK for 2nd Battery
Toolmaker Metalworks - to me announced.....
My goal here was to really improve the Bass and not get to carried away with over all weight. Reasons why I went with a Single Sub set-up, Smaller sized Amp, Birch wood and a smaller lighter weight 2nd Battery.
Now as I post pictures and start this build. I will need some help and have some questions. I'm sure of it. I will also be giving my opinion and reviews on products as I go.
I noticed with my old set up. Just a single Memphis PR 10inch. That a lot of my bass was lost before it made it into the Cabin. So To fixed this issue. I'm moving up from a 500w set up to a 1500w-ish set up. I'm also running a 6 inch port through the rear deck. The sub will be firing off the side of the trunk just behind the seats. The port once it is through the rear deck is about 1in away from the back glass(at its closet point) I'm hoping the combination of all this will dramatically improve my Bass.
Also with my last set up. Just that 500.1 Prime Amp pulled enough to Dim my lights and slow my idle at hard bass hits. So to help fix this b/c it was already a problem and I knew it would just get worse. I'm jumping up from a stock 140a Alternator to the Mechman 240a which as an idle output higher then my stock could put out at max. I'm also switching out my Stock Lead Acid battery for a Big AGM from Odyssey and a 2nd Battery from XS Power. I will be also adding a BIG 3 kit. My car already has a 0g from Alt. to Battery. So I will be adding 0g for my grounds and a 0g from Alt. to Starter.
That's were I'm at now... If you see anything I need to address. Let me know...
Reply With Quote Quick reply to this message
Sponsored Links
Advertisement

  #2
Old 03-21-2015, 01:33 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

Pic's will come very soon... I can post a teaser of the Box... Will have more pictures of the box soon.. CSCStang has been great at sending me updates. We hit s small hick-up, on measurements from AB but we are squared away now.
Box Size 26.75 x 17.75 x 15
Reply With Quote Quick reply to this message
  #3
Old 03-21-2015, 01:35 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

Couple more Box Build Pictures.

Reply With Quote Quick reply to this message

  #4
Old 03-21-2015, 01:35 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

More Box Pic's....I'll get everything out of the box and get pictures up tomorrow.




Reply With Quote Quick reply to this message
  #5
Old 03-21-2015, 01:36 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

Electrical Upgrades

Last edited by Jeffhulbert50; 04-12-2015 at 12:41 AM.
Reply With Quote Quick reply to this message
  #6
Old 03-21-2015, 01:37 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

Parts Pics








[/QUOTE]
Reply With Quote Quick reply to this message
  #7
Old 03-21-2015, 01:38 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

Updated Pictures of the Box



Reply With Quote Quick reply to this message
  #8
Old 03-21-2015, 01:40 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

Another update..


Reply With Quote Quick reply to this message
  #9
Old 03-21-2015, 01:41 AM
Ramrod's Avatar
New CACO Member

Activity Longevity
0/20 9/20
Today Posts
0/11 sssssss50
Location: MO
Thanks: 11
Thanked 1 Time in 1 Post
iTrader: (0)
Feedback Score: 0 reviews
Default

Box is all done.. Should have it any day now.. Can't Wait..



Reply With Quote Quick reply to this message
  #10
Old 03-23-2015, 08:08 AM
massivespl's Avatar
Elite Member

Activity Longevity
1/20 17/20
Today Posts
0/11 sssss8409
Location: michigan
Thanks: 410
Thanked 735 Times in 568 Posts
iTrader: (39)
Feedback Score: 39 reviews
Default

Box looks real nice.
__________________
C-pillar flat wall best score: 158.6db
1 vital power 700.1 @ .33ohm
4 NSV3 18s
8 pwx crescendo 10s
Quad excessive amperage 350alts
4 juicebox 3100s
